FX+ 1S is a versatile and fast throttle e-bike built for cruising through town. Its handlebar throttle makes getting up to speed a breeze, and pedal assist gives a smooth boost.
FX+ 1S is a versatile and fast throttle e-bike built for cruising through town. Its handlebar throttle makes getting up to speed a breeze, and pedal assist gives a smooth boost.
Trek

Trek FX+ 1S All Road Step Over Throttle E-Hyrid Bike In Dark Star

$2,099.99
Preorder

With Pre-Order, you can purchase the latest items added to our store in advance of them arriving with us.

Your Pre-Order is prioritized (at no additional charge); meaning that as soon as the product arrives with us, we can wrap it straight back up; ready for collection via Click & Collect or dispatch to you — it often never even hits the stock room shelves!

Prelaunch

With Prelaunch, the date when we expect to receive the product ourselves is still a little too hazy to be confident in accepting Preorders.

So, instead, you can submit your email address for the item you are interested in, and we will email you as soon as stock arrives in the system.

Estimated Delivery & Collection Dates

Estimated Delivery & Collection Dates are given on Pre-Order and Pre-Launch products. They are for indicative purposes only and can change at any time without notice.

The dates we provide are based on information given by our suppliers. Whenever we get updated information from our suppliers we will endeavor to update the Estimated Delivery & Collection Dates provided on product pages.

We estimate this will be ready for dispatch to you or collection via Click & Collect on Undetermined

Trek FX+ 1S All Road Step Over Throttle E-Hyrid Bike In Dark Star

Season:2026

Brand:Trek

Code:49668BLK

The FX+ 1S is a versatile and fast throttle e-bike built for cruising through town with a smile.

The FX+ 1S is a versatile and fast throttle e-bike built for cruising through town. Its handlebar throttle makes getting up to speed a breeze, and pedal assist gives you a smooth boost while you ride. Plus, an EasyMag magnetic charger with a sleek, portable wall-mounted system makes charging between rides easier than ever. This e-bike adds ease to everything, from getting up to speed to charging the battery between rides. It offers confident, stable handling on bike paths and rail trails, plus integrated lights and turn signals to boost safety.

It features a lightweight Alpha Gold Aluminum frame with comfortable geometry and a Hyena hub-drive motor capable of speeds up to 32km/h (20mph) with the throttle or 45km/h (28mph) with pedal assist. A 520Wh integrated battery and full-color display are included, along with a portable wall-mount magnetic charger. Integrated lights, turn signals with brake light function, and a kickstand are fitted. It is finished off with 8-speed Shimano Essa shifting, wide and stable 50mm tires, and hydraulic disk brakes.

With the push of a button, the easy-to-use throttle lets you flatten hills, ride further, and adventure longer, without breaking a sweat. The FX+ 1 pairs with the Trek Central app so you can easily adjust the bike's settings for longer range, map the perfect routes, and track ride stats.

Starting in 2024, Trek began removing high-emission aluminum from manufacturing and replacing it with low-emission aluminum made with renewable energy. By October 2025, nearly every alloy bike made by Trek, including this one, had made the switch, driving a major drop in the footprint. The e-systems on Trek e-bikes are third-party tested to meet the latest e-bike safety regulations, including the stringent UL 2849 certification.

Features:

  • You get the convenience of a throttle for accelerating and the smooth support of pedal assist while you ride.
  • The portable magnetic wall-mount charger makes getting the battery ready to ride a hassle-free process.
  • Wide, stable 50mm tires deliver tons of traction and confidence for riding through town, on paths, and on rail trails.
  • Integrated lights, turn signals, and brake light help you see and be seen wherever you roll.
  • You get low-maintenance, reliable shifting thanks to Shimano's 8-speed Essa drivetrain.
  • The EasyMag system is designed with a hassle-free magnetic attachment to charge, bright LED status lights, and an optional wall mount, allowing charging at home or on the go.
  • Wheel size is 70cm (27.5").
  • Range is up to 80km (50mi).
Technical Information
  • Frame
    Alpha Gold Aluminum, internal cable routing, internal battery, rack & fender mounts, flat mount disk brake, kickstand mount, 144.5mm OLD hub motor spacing
  • Fork
    Alloy, internal brake routing, fender mounts, rack mounts, ThruSkew 5mm bolt-on skewer
  • Hub front
    Alloy low-flange w/6-bolt disk, 36h, w/QR
  • Skewer front
    132x5mm QR, ThruSkew
  • Rim
    Alloy double wall, 36h
  • Tire
    Bontrager GR0 Comp, wire bead, 60 tpi, 650x50mm
  • Max tire size
    650x50mm
  • Battery
    520Wh, integrated in down tube
  • Charger
    Trek Easy Mag charger, 2.7A, 54.9V output, 100V-240V AC input
  • Computer
    LCD display
  • Motor
    Hub drive motor, 60 Nm, 500W, 36H, black
  • E-bike Classification
    Class 2/3 hybrid
  • Shifter
    Shimano M315, 8 speed
  • Rear derailleur
    Shimano ESSA U2000
  • Crank
    Alloy, 40T steel chainring, 170mm length
  • Cassette
    Shimano HG400, 11-45, 8 speed
  • Chain
    KMC Z8.3
  • Pedal
    Bontrager City pedals
  • Max chainring size
    1x: 40T
  • Saddle
    Bontrager Sport
  • Seatpost
    Size: S, M: Bontrager alloy, 31.6mm, 12mm offset, 330mm length; Size: L, XL: Bontrager alloy, 31.6mm, 12mm offset, 400mm length
  • Handlebar
    Size: S, M: Bontrager alloy, 31.8mm, 15mm rise, 690mm width; Size: L, XL: Bontrager alloy, 31.8mm, 15mm rise, 720mm width
  • Grips
    Bontrager XR Endurance Comp, lock-on
  • Stem
    Size: S, M: Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 80mm length; Size: L, XL: Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 90mm length
  • Brake
    Rush BH-286 hydraulic disk, 180mm rotor
  • Rotor size
    Max brake rotor sizes: 180mm front & rear
  • Light
    Size: S, M, L, XL: Sate-Lite M-15 with turn signal and brake light function; Size: S, M, L, XL: Herrmans MR8, 180 lumen, 60 lux, LED headlight
  • Kickstand
    Adjustable length alloy kickstand
  • Weight
    M - 22.10 kg / 48.73 lbs
  • Weight limit
    This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).
