Frame
Cutthroat C
-
Color
Tangerine
-
Fork
Cutthroat Carbon Deluxe
-
Headset
FSA NO.42/ACB
-
Seatpost
TranzX YSP38 dropper post, 90mm travel
-
Stem
Salsa Guide
-
Grips/bar tape
Velo anti-slip, shock-proof silicone tape
-
Saddle
WTB SL8 Medium Steel SL
-
Handlebar
Salsa Cowchipper
-
Rear derailleur
SRAM S1000 Eagle Transmission
-
Cassette
SRAM XS-1270, T-Type 10–52t, 12-speed
-
Chain
SRAM GX T-Type
-
Crankset
SRAM STYLO 6K Eagle DUB, 34t
-
Shifter
SRAM Apex AXS, D1
-
Brake levers
SRAM Apex hydraulic disk brakes
-
Brake calipers
SRAM Apex hydraulic disk brakes
-
Rotors
SRAM CenterLine rotors (Center Lock, 160mm)
-
Front wheel
Shimano TC500-15-B 15 x 110mm hub, WTB KOM Team 25mm TCS 2.0 29" rim, 32h (taped, WTB tubeless valve included)
-
Rear wheel
Shimano TC500-HM-B 12 x 148mm hub, WTB KOM Team 25mm TCS 2.0 29" rim, 32h (taped, WTB tubeless valve included)
-
Front tire
Teravail Sparwood, 29 x 2.2", Durable casing, tubeless-ready
-
Complete bike weight
25 lbs 0 oz (56cm size)
-
Design wheel/tire sizes
29 x 2.25" (29 x 2.4" Max) (Some front derailleurs may reduce tire clearance. Check manufacturer’s specifications to confirm clearance before installing.)
-
Suspension fork length (travel)
506 mm (100 mm Travel)
-
Rigid fork length
483 mm
-
Fork offset
51 mm
-
Rear spacing
148 x 12 mm Thru-axle
-
Rear axle size
M12 x P1.0 x 175
-
Rear brake (rotor)
Flat mount (140–160 mm), flat mount frame standard (25mm Thickness), 32 mm bolt length
-
Front brake (rotor)
Flat mount (160–180 mm), flat mount frame standard (35 mm thickness), 42 mm bolt length
-
Headset - upper
IS41
-
Headset - lower
IS52
-
Front spacing
110 x 15 mm Thru-axle
-
Seatpost (Frame Specs)
27.2 mm
-
Dropper post compatible
Yes, internal. For Internal Dropper Post Routing: 1x mechanical drivetrain: Route the dropper post cable through the drive side of the down tube. Di2 drivetrains: Mount the Di2 battery in the seatpost, then route the dropper post cable through the drive side of the downtube; For External Dropper Post Routing: 1x and 2x mechanical and Di2 drivetrains:Route the dropper post cable through the dynamo rear light holes on the non-drive side of the top tube.
-
Seatpost clamp
32.0 mm
-
Front derailleur type
Road, braze-on, 2x, bottom-pull
-
Derailluer hanger
SRAM UDH
-
Bottom bracket
Press Fit BB92, 41 x 92 mm
-
Crankset (max ring)
1x MTN Boost: 40t Max; 2x RD Boost outer ring: 46–50t, inner ring: 30–36t *Oval chainrings subtract 2t from max*
-
Accessory mounts
Front Rack Mounts: Yes, lowrider compatible. Salsa Down Under rack recommended; Rear Rack Mounts: Yes, Salsa Rack Lock seatpost collar required. Salsa Wanderlust Rack recommended. Salsa Bent Rack Struts (part #RK8030) required for installation on 58 cm and 60 cm frames. Not compatible with Salsa Wanderlust HD Rack; Under Downtube Mount: Yes, two pair; Top Tube Mounts: Yes, compatible with Salsa Top Tube bag
-
Bottle mounts
Frames up to 54cm: 2 in main triangle. Frames 56cm and larger: 3 in main triangle.
-
Fork mounts
Yes, one set of Three-Pack mounts on each fork leg
-
Geometry - Head tube angle
69.0 degrees for all sizes (52cm to 60cm)
-
Geometry - BB drop
70.0 for all sizes (52cm to 60cm)
-
Geometry - Chainstay length
445.0 for all sizes (52cm to 60cm)
-
Geometry - Fork length axle to crown
483.0 for all sizes (52cm to 60cm)
-
Geometry - Fork offset
51.0 for all sizes (52cm to 60cm)
-
